Cap, LT Vang
Piston, Coax P/P Feed
Stop Tube
Ext. Tube
Extension Tube Cap
Vang Dam P/P PI
Header MTG Anchor
Trans Tube Connector
Wiper Mount
Slider RMount Tube
Slider Mount Bearing
22
Vang Lockpin #23
Duncan 550mm Trans Rail
Duncan 550mm Trans Slider
Coaxial Gland
Coaxial Gland
Piston Rod
Coaxial Feed Tube
THD Clevis Pin
THD Clevis Pin
Clevis Pin Nut
Clevis Pin Nut
Cotter Pin #32
Roll Pin
Roll Pinf
6 C5OX-SS Fitting
6 C5OX-SS Fitting
O-Ring
O-Ring
O-Ring
O-Ring
O-Ring
O-Ring
O-Ring
O-Ring
O-Ring #45
O-Ring Backup
O-Ring Backup
O-Ring Backup
O-Ring Backup
O-Ring Backup
O-Ring Backup
O-Ring Backup
O-Ring Backup
O-Ring Backup
O-Ring Backup
*Included in Seal Kit
| Item # | Part # | Description | Qty |
|---|---|---|---|
| A850-SK-xxx | Seal Kit * | ||
| 1 | A090-16-01 | Label, “NAVTEC” Medium 2.4″ x 1″ | 1 |
| 2 | A090-19-01 | Label, “DANGER” w/ Model & Serial # CUSTOM** 2″ x 1 3/4″ | 1 |
| 3 | A251-08-xxx | Piston Lock Pin | 1 |
| 4 | A251-12-xxxP | Piston Bearing for PIP Ring | 2* |
| 5 | A251-23Vxxx | Cap, LT Vang | 1 |
| 6 | A251-24Cxxx | Gland Backup Delrin | 1 |
| 7 | A251-25Vxxx | Gland, LT Vang Deep Seal | 1 |
| 8 | A251-29VPIxxxPP | Piston, Coax P/P Feed | 1 |
| 9 | A851-01-xxx | Oil Jaw | 1 |
| 10 | A851-02Vxxx | Stop Tube | 1 |
| 11 | A851-03-xxxPP | Ext. Tube | 1 |
| 12 | A851-05PIxxxPP | Pressure Clevis | 1 |
| 13 | A851-06PIxxxA | Vang Tube (Specify Length) | 1 |
| 14 | A851-12-xxxA | Extension Tube Cap | 1 |
| 15 | A851-13-xxx | Spacer | 1 |
| 16 | A851-14-xxxPI | Vang Dam P/P PI | 1 |
| 17 | A851-30-xxx | Header MTG Anchor | 1 |
| 18 | A851-31-xxA | Trans Tube Connector | 1 |
| 19 | A851-32-xx | Wiper Mount | 1 |
| 20 | A851-33-xx | Slider RMount Tube | 1 |
| 21 | A851-34-xxx | Slider Mount Bearing | 1 |
| 22 | A851-35-xx | Anchor Pin | 1 |
| 23 | A851-36-xx | Vang Lockpin | 1 |
| 24 | A851-37-550-A | Duncan 550mm Trans Rail | 1 |
| 25 | A851-37-550-B | Duncan 550mm Trans Slider | 1 |
| 26 | A851-50-xx | Port Plug Assembly | 1 |
| 27 | A951-02-0438-02 | Coaxial Gland | 2 |
| 28 | A951-07-xxx-xx | Piston Rod | 1 |
| 29 | A951-12-xxx-xx | Coaxial Feed Tube | 1 |
| 30 | D602-1000-27201 | THD Clevis Pin | 2 |
| 31 | D602-NUT-087501 | Clevis Pin Nut | 2 |
| 32 | D660-0832 | Cotter Pin | 1 |
| 33 | D662-014 | Roll Pin | 2 |
| 34 | HB-364 | 6 C5OX-SS Fitting | 2 |
| 35 | HC-007 | 1/4-20 x 1/2 Cone Point Socket Set Screw SS | 1 |
| 36 | HC-038 | 10-32 x 3/16″ Cup Point Socket Set Screw SS | 1 |
| 37 | HC-162 | 10-32 x 1/4″ Cup Point Socket Set Screw SS | 3 |
| 38 | HG-008 | Retaining Ring, 1″ for PI Wiper Mount | 1 |
| 39 | HH-006 | 1/16″ NPT Socket Pipe Plug SS | 1 |
| 40 | HI-0xx | Rod Seal | 1 |
| 41 | HJ-x-xxx | O-Ring | 2 |
| 42 | HJ-x-xxx | O-Ring | 1 |
| 43 | HJ-x-xxx | O-Ring | 2 |
| 44 | HJ-x-xxx | O-Ring | 3 |
| 45 | HJ-x-xxx | O-Ring | 1 |
| 46 | HK-x-xxx | O-Ring Backup | 4 |
| 47 | HK-x-xxx | O-Ring Backup | 1 |
| 48 | HK-x-xxx | O-Ring Backup | 2 |
| 49 | HK-x-xxx | O-Ring Backup | 3 |
| 50 | HL-0xx | PIP Rings | 1 |
| 51 | HM-014 | Piston Seals | 1 |
| 52 | HN-008 | Rod Wipers | 1 |
