Clevis Pin
Oil Jaw
JIC Short Elbow, SS
O-Ring
Backup O-Ring
Piston Rod
Cup Point Socket Set Screw SS
Cup Point Socket Set Screw SS
Cup Point Socket Set Screw SS
Rod Stop Bushing
Gland Backup
O-Ring
O-Ring
O-Ring Backup
O-Ring Backup
Rod Stop Bushing
Piston Locking Pin
Piston Bearing, PIP Ring
Piston Bearing, PIP Ring
Piston, Light Cylinder
PI Vang Tube
PI Vang Piston Adaptor
Port Plug, 3/8″ Hardcoat, Black
Port Plug, 3/8″ Hardcoat, Black
Check Spring, Small, Port Plug Check Bob
1/4″ Hard Steel Ball
Tube Conn PI Vang
Cotter Pin
PI Header Mounting Anchor
PI Slider Mount Bearing
PI Vang Lock Pin
Gas Clevis
Piston Seal
PIP Ring
Gland
Rod Seal
Rod Wiper
Cotter Pin
PI Vang Wiper Mount
Slider Mount Tube PI Vang
O-Ring
O-Ring
PI Aluminum HDR Anchor Pin
NPT Socket Pipe Plug SS
PI Module
RET Ring
PI Plug & Cable Ass’y, 6.5′ long
Tube Conn PI Vang
SPIRS100S RET Ring
To determine which Size Vang you have, Measure Tube and Piston Rod OD, and See: Product Specifications – A850 Vang.
* Included in Seal Kit
| Item # | Part # | Description | Qty |
|---|---|---|---|
| A850-SK-xxxPI | Seal Kit * | ||
| 0 | A090-19-01 | Label, “DANGER” w/ Model & Serial # CUSTOM** 2″ x 1 3/4″ | 1 |
| 0 | A090-34-01 | Label, “NAVTEC” Large 2.95″ x 1.08″ | 1 |
| 1 | D600-xx-xxx | Clevis Pin | 2 |
| 2 | A851-01-xxx | Oil Jaw | 1 |
| 3 | HB-069 | JIC Short Elbow | 1 |
| 4 | HJ-x-xxx | O-Ring | 1* |
| 5 | HK-x-xxx | O-Ring Backup | 1* |
| 6 | A851-07-xxx | Piston Rod | 1 |
| 7 | HC-038 | Cup Point Socket Set Screw | 6 |
| 8 | A251-03Vxxx | Cap | 1 |
| 9 | A251-04Cxxx | Gland Backup | 1 |
| 10 | HJ-x-xxx | O-Ring | 3* |
| 11 | HK-x-xxx | O-Ring Backup | 3* |
| 12 | A251-02Vxxx | Rod Stop Bushing | 1 |
| 13 | A251-08-xxx | Piston Lock Pin | 1 |
| 14 | A251-12-xxxP | Piston Bearing, Pip Ring | 2* |
| 15 | A251-29-xxx | Piston, Light Cylinder | 1 |
| 16 | A851-06PIxxx | Tube | 1 |
| 17 | A851-29-xxx | PI Vang Piston Adaptor | 1 |
| 18 | A031-19-02 | Port Plug, 3/8″ Hardcoat, Black | 2 |
| 19 | A031-02-01 | Check Spring, Small, Port Plug Check Bob | 1* |
| 20 | HD-00-250 | 1/4″ Hard Steel Ball | 1* |
| 21 | A851-31-01A | Tube Connector PI Vang | 1 |
| 22 | D660-0832 | Cotter Pins | 1 |
| 23 | A851-30-xxx | PI Header Mounting Anchor | 1 |
| 24 | A851-34-xxx | PI Slider Mount Bearing | 1 |
| 25 | A851-36-02 | PI Vang Lock Pin, 3/16″ x 1″ | 1 |
| 26 | A851-05PIxxx | Gas Clevis | 1 |
| 27 | HM-0xx | Piston Seal | 1* |
| 28 | HL-0xx | Pip Ring | 1* |
| 29 | A251-05Vxxx | Gland | 1 |
| 30 | HI-0xx | Rod Seal | 1* |
| 31 | HN-0xx | Rod Wiper | 1* |
| 32 | D660-1248 | Cotter Pin | 2 |
| 33 | A851-32-01 | PI Vang Wiper Mount | 1 |
| 34 | A851-33-01 | Slider Mount Tube PI Vang | 1 |
| 35 | HJ-x-xxx | O-Ring | 3* |
| 36 | A851-35-01 | PI Aluminum Header Anchor Pin | 1 |
| 37 | HH-006 | 1/16″ NPT Socket Pipe Plug SS | 1 |
| 38 | A851-37-550 | PI Module | 1 |
| 39 | HG-008 | Retaining Ring, 1″ for PI Wiper Mount | 1* |
| 40A | A851-50-04 | PI Plug & Cable Ass’y, 6.5′ long | 1 |
| 40B | A851-50-05 | PI Plug & Cable Ass’y, 33′ long | 1 |
