A850 Vang Breakdown -6/-10/-12 – Owner’s Manual

To determine which Size Vang you have, Measure Tube and Piston Rod OD, and See: Product Specifications – A850 Vang.
* Included in Seal Kit

Item #	Part #	Description	Qty
	A850-SK-xxx	Seal Kit *
0	A090-16-01	Label, “NAVTEC” Medium 2.4″ x 1″	1
0	A090-19-01	Label, “DANGER” w/ Model & Serial # CUSTOM** 2″ x 1 3/4″	1
1	D600-xx-xxx	Clevis Pin	2
2	A851-01-xxx	Oil Jaw	1
3	HB-069	1/8″ NPT x 1/4″ JIC Short Elbow, SS	1
4	HJ-x-xxx	O-Ring	1*
5	A851-07-xxx	Piston Rod	1
6	A251-03Vxxx	Cap	1
7	HC-038	10-32 x 3/16″ Cup Point Socket Set Screw SS	1
8	A251-04Cxxx	Gland Backup	1
9	A251-05Vxxx	Gland	1
10	HJ-x-xxx	O-Ring	3*
11	A251-02Vxxx	Rod Stop Bushing	1
12	A851-06-xxx	Vang Tube (Specify Length)	1
13	A251-08-xxx	Piston Lock Pin	1
14	HL-0xx	Pip Ring	1*
15	A251-29-xxx	Piston, Light Cylinder	1
16	HJ-x-xxx	O-Ring	2*
17	A031-02-01	Check Spring, Small, Port Plug Check Bob	1*
18	A851-10-xxx	Lock Pin for Pressure Clevis	2
19	A851-08-xxx	Sleeve	1
20	HJ-x-xxx	O-Ring	1*
21	HG-0xx	Spiral Retaining Ring for Vang	1*
22	A851-05-xxx	Pressure Clevis	1
23	A851-09-xxx	Lock nut	1
24	HD-00-250	1/4″ Hard Steel Ball	1*
25	A031-19-02	Port Plug, 3/8″ Hardcoat, Black	2
26	A251-12-xxxP	Piston Bearing PIP Ring	2*
27	HM-0xx	Piston Seal	1*
28	HK-x-xxx	O-Ring Backup	3*
29	HI-0xx/HM-0xx	Rod Seal	1*
30	HN-0xx	Rod Wiper	1*
31	HK-x-xxx	O-Ring Backup	1*
32	D660-1040	Cotter Pins	2

* Included in Seal Kit
