Clevis Pin
Oil Jaw
JIC Short Elbow
O-Ring
O-Ring Backup
Piston Rod
Cup Point Socket Set Screw
Cap
Gland Backup
O-Ring
O-Ring
O-Ring Backup
O-Ring Backup
Rod Stop Bushing
Piston Lock Pin
Piston Bearing, Pip Ring
Piton, Light Cylinder
Vang Tube
Vang Extension Tube (Specify Length)
Port Plug
Port Plug
Check Spring, Small, Port Plug Check Bob
1/4″ Hard Steel Ball
O-Ring
O-Ring Backup
Lock Pin for Pressure Clevis
Sleeve
Lock Nut
Pressure Clevis
Piston Ring
Pip Ring
Gland
Rod Seal
Rod Wiper
Cotter Pin
Cotter Pin
Spiral Retaining Ring
O-Ring
O-Ring
O-Ring
Clevis Pin
To determine which Size Vang you have, Measure Tube and Piston Rod OD, and See: Product Specifications – A850 Vang.
* Included in Seal Kit
Item # | Part # | Description | Qty |
---|---|---|---|
A850-SK-xxx | Seal Kit * | ||
0 | A090-19-01 | Label, “DANGER” w/ Model & Serial # CUSTOM** 2″ x 1 3/4″ | 1 |
0 | A090-34-01 | Label, “NAVTEC” Large 2.95″ x 1.08″ | 1 |
0 | HR-020 | 1/4″ JIC Brass Cap | 1 |
1 | D600-xx-xxx | Clevis Pin | 2 |
2 | A851-01-xxx | Oil Jaw | 1 |
3 | HB-069 | 1/8″ NPT x 1/4″ JIC Short Elbow, SS | 1 |
4 | HJ-x-xxx | O-Ring | 1* |
5 | HK-8-xxx | O-Ring Backup | 1* |
6 | A851-07-xxx | Piston Rod | 1 |
7 | HC-038 | Cup Point Socket Set Screw | 2 |
8 | A251-03Vxxx | Cap | 1 |
9 | A251-04Cxxx | Gland Backup | 1 |
10 | HJ-x-xxx | O-Ring | 3* |
11 | HK-8-xxx | O-Ring Backup | 3* |
12 | A251-02Vxxx | Rod Stop Bushing | 1 |
13 | A251-08-xxx | Piston Lock Pin | 1 |
14 | A251-12-xxxP | Piston Bearing, Pip Ring | 2* |
15 | A251-29-xxx | Piston, Light Cylinder | 1 |
16 | A851-06-xxx | Vang Tube | 1 |
17 | A851-03-xxx | Vang Extension Tube (Specify Length) | 1 |
18 | A031-19-02 | Port Plug, 3/8″ Hardcoat, Black | 2 |
19 | A031-02-01 | Check Spring, Small, Port Plug Check Bob | 1* |
20 | HD-00-250 | 1/4″ Hard Steel Ball | 1* |
21 | HJ-x-xxx | O-Ring | 2* |
22 | HK-8-xxx | O-Ring Backup | 2* |
23 | A851-10-xxx | Lock Pin for Pressure Clevis | 2 |
24 | A851-08-xxx | Sleeve | 1 |
25 | A851-09-xxx | Lock Nut | 1 |
26 | A851-05-xxx | Pressure Clevis | 1 |
27 | HM-0xx | Piston Seal | 1* |
28 | HL-0xx | Pip Ring | 1* |
29 | A251-05Vxxx | Gland | 1 |
30 | HI-0xx | Rod Seal | 1* |
31 | HN-0xx | Rod Wiper | 1* |
32 | D660-1248 | Cotter Pin | 2 |
33 | HG-0xx | Spiral Retaining Ring | 1* |
34 | HJ-x-xxx | O-Ring | 1* |
35 | HJ-x-xxx | O-Ring | 2* |
